PLC Core Components Semi-Automatic Ice Packing Machine for Plastic Packaging Material

Name: PLC Core Components SemiAutomatic Ice Packing Machine for Plastic Packaging Material
Brand: Focusun
Price: 4 USD

Wholesale PLC Core Components Semi-Automatic Ice Packing Machine for Plastic Packaging Material from china suppliers

Warranty : 1.5 years, 15 Months

Type : Other, semi-automatic ice packing machine

Applicable Industries : Ice factory

Showroom Location : None

Video outgoing-inspection : Provided

Machinery Test Report : Not Available

Warranty of core components : 1.5 years

Core Components : PLC, Motor

Condition : New

Application : Ice factory, packing ice

Packaging Type : Bags

Packaging Material : Plastic

Automatic Grade : Semi-automatic

Driven Type : Electric

Voltage : 240v, 380v

Power : 0.75kw

Place of Origin : Shanghai, China

Brand Name : Focusun

Weight : 300kg

Dimension(L*W*H) : 2320*880*1890

Key Selling Points : Easy to Operate

Name : Semi-automatic ice packing machine

Compressor : Bitzer

Keyword : ice packer

Material : Stainless Steel 304

Power supply : 380V/3P/50HZ

Capacity : 500KG/hr

After Warranty Service : Video technical support, Online support

Local Service Location : None

Marketing Type : Ordinary Product

After-sales Service Provided : Video technical support

Packaging Details : standard wood packages with protection film and transport in container

Port : shanghai port

Supply Ability : 100 Set/Sets per Quarter

Price : $4,500.00/sets >=1 sets

MOQ : 1pc

Contact Now

About Focusun

PLC Core Components Semi-Automatic Ice Packing Machine for Plastic Packaging Material

FOCUSUN---Cooling Technical Master Since 1929, Germany

Focusun is a pioneer in ice cooling techlonogy and manufacture worldwide. We mainly design and manufacture tube ice machine, block ice machine, flake ice machine, cube ice machine, plate ice machine, water chiller, concrete cooling system, automatic ice storage system, dynamic ice storage system and all kinds of cold rooms. Over a decade, we have provided quality service to more than 16,000 professional clients in 150 countries around the world. Now we have a factory of 36,000 square meter in Taizhou, Jiangsu province, China.

Focusun (shanghai) Refrigeration Equipment is founded in 2008. In fact, our activity in refrigeration technology is dated back to 2002. In 2012. Focusun(Shanghai) is authorized by Kulinder Incorporation(Germany) to deal with all business, D&M and promotion in China and granted the full right to use the brand of Kulinder, Focusun, pictures and the copyright of design &manufacture in China.

Product Description

Semi-automatic ice packaging machine :

After many years of experience in ice machine of designing and manufacturing, in order to meet the in-creasing demand for an ice packing machine, Focusun in 2014 developed an efficient bagging machine for tube ice and cube ice.

Focusun FP-01D is a basic model of semi-automatic ice packaging machine for commercial use. It has a simple and neat structure, high quality SUS304 covered contact area, and light weight design that allow you to mobile it anywhere you want to pack ice. Single alternator powered, auger type ice delivery, all these designing aspects are focusing on materializing a simple, reliable and low cost ice packing solution.

System configuration:
Main alternator: Panasonic (Japan)

Compressor: AIRTAC (Taiwan)

Sensor: Omron (Japan)

Switch board: Chint (China)

Model	Packing speed	Dimention(mm)	kg/bag	Screw length	Diameter
FIP-01D-Ⅰ	500kg/hour	19806001775	200g-5kg	2400mm	150mm
FIP-01D-Ⅱ	1000kg/hour	23208801890	5kg-20kg	2400mm	180mm

Technical parameters:

*advances ice lifting by screw technology, stainless steel 304 material screw standard size 1740*Ø190mm, speed 60 rotation per miunte, can be customized if special demand;
*overload protect design, power cut down automatically if current too high;
*pulley design makes movable machine;
*packing 500~1000kg per hour;
*power consumption: 0.75Kw;
*Size 2,320*880*1,890 L*W*H mm.

An worker is required to stand by, hold the ice bags and tie bags manually with ropes.

Detailed Images

Machine Parts

pulley design makes movable machine;

packing 500~1000kg per hour;

Machine Parts

power consumption: 0.75 Kw;

Size 2,320*880*1,890 L*W*H mm.

Machine Parts

advances ice lifting by screw technology, stainless steel 304 material screw standard size 1740*Ø190mm, speed 60 rotation per miunte, can be customized if special demand;

overload protect design, power cut down automatically if current too high;

Certifications

Cube ice machine

91.8% Response Rate

Tube ice machine

91.8% Response Rate

Block ice machine

91.8% Response Rate

Our Service

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

Also other products:
Focusun flake ice plant series: http://www.flake-ice-plant.com/
Focusun tube ice plant series: http://www.tube-ice-plant.com/
Focusun block ice plant series: http://www.block-ice-plant.com/
If you are considering to purchase an block ice machine, or you are just want to know information about the block ice machine and prepare your business for future, please feel free to contact Focusun sales team.

To make customer have better understanding, our Focusun company launched a new website and totally explains the different block ice machines. Can you visit here : http://www.block-ice-plant.com

We are very interested to have your inquiry.
We are looking forward to give our best supports.
We are also welcome your visit to FOCUSUN CHINA FACTORY to have face-to-face meeting with our engineering team.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.

Packing & Delivery

PACKING DETAILS

The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.
